TOSHIBA BX430T Series
TOSHIBA BX430T series is a high resolution industrial printer and delivers 600 dpi printing with micro-labelling capabilities for ultra-precise applications.
- Perfect for electronic component and PCB labelling, with label sizes as small as 13 x 3 mm.
- New high-function fabric cutter with kicker supports care label production in the garment industry.
- High-precision peel-off module for advanced and easy label handling.
Furthermore, the BX430T series is equipped with a new platform 'A-BRID' that realizes flexible expandability, providing various solutions to adapt to the ever-changing needs of the workplace.
Web Utility is enabled by A-BRID.
> Click here to learn more about Web Utility
Specifications
| BX430T | |
|---|---|
| Model | HS02 |
| CHARACTERISTICS | |
| Printhead | Flat head |
| Print Method | Thermal transfer / Direct thermal |
| Memory | 1 GB RAM, 8 GB ROM |
| Dimensions (W x D x H) | 278 mm x 460 mm x 310 mm (10.94" x 18.11" x 12.20") |
| Weight | 17.0 kg (37.47 lb) |
| User Interface | Color LCD(with LED backlight), 11Keys, 272 x 480 dots Graphic LCD |
| Operating Temp./Humidity | 5°C to 40°C (41°F to 104°F) 25% to 85% RH (no condensation) |
| Power Supply | AC100 to 240V, 50/60 Hz |
| Resolution | 600 dpi (24dot/mm) |
| Print Speed (max.) | 152.8 mm/sec (6"/sec.) |
| Print Width (max.) | 104 mm (4.09”) |
| Print Length (max.) | 498 mm (19.6") |
| RIBBON | |
| Width | 40 mm to 115 mm(1.57" to 4.52") |
| Length | 300 m(11811.02') |
| MEDIA | |
| Alignment | Centered |
| Media (backing paper) Width (min. - max.) |
25 mm to 110 mm (0.98" to 4.33") |
| Label Thickness | 0.13 mm to 0.17 mm (0.005" to 0.006") |
| Inner Media Core Diameter | 76.2 mm (3"), 50.8 mm (2") |
| Outer Media Roll Diameter (max.) | ?200 mm (?7.87") |
| Media format | Roll, fanfold |
| SOFTWARE & CONNECTIVITY | |
| Emulations | Auto-detection of TPCL, ZPL II, DPL, SBPL, PDF |
| Printer Driver | Windows 11/10, Windows Server 2019/2016, SAP, CUPS driver for Linux, macOS |
| SDK | iOS, Android, Windows, Java |
| Interface | USB 2.0 HS (USB host/HID support), LAN10/100/1000 BaseT, RS232C(1), WLAN802.11ac/a/b/g/n/ax(1)(2), Bluetooth 5.2(1)(2), Expansion I/O(1) |
| Language mode | TPCL |
| Label software | NiceLabel free, BarTender UltraLite |
| IoT device management | e-BRIDGE CloudConnect |
| OPTIONS | |
| Disc cutter module, Cutter for Care label, Peel-off module, External media guide, RS232, Wireless communication module, EX I/O, Real Time Clock kit, High accuracy Peel-off module | |
*1: Optional
*2: Availability varies from country to country
