TOSHIBA B-EX6T
The Toshiba B-EX6 series - redefining the Industrial printer marketplace. Combining market leading technology with usability, reliability and the lowest total cost of ownership. Extending the capabilities of our existing range of B-EX printers to cover the most demanding applications, for heavy duty industrial printing. Rugged and durable design, advanced functionality, cost saving features and a wide choice of models and options for the best “all-in-one” industrial solution.
Specifications
| B-EX6T1-GS/TS12 | B-EX6T3-GS/TS12 | |
|---|---|---|
| CHARACTERISTICS | ||
| Printhead | Near-edge head | Near-edge head with cool down bar |
| Dimensions | 331 (W) x 480 (D) x 310 (H) mm | |
| Weight | 20 kg | |
| User interface | Graphic LCD, 2 x LED, 10 x key | |
| Operating Temperature | 5 - 40°C (41 - 104°F) / 25 - 85% non-condensing relative humidity (RH) |
|
| Standard Interface | USB 2.0, LAN 10/100 Base, IPv6, USB Host/RTC, | |
| Optional Interface | RS232, Centronics, Wireless LAN, EX I/O | |
| Memory | System (Flash Memory) 64MB, SRAM 32MB | |
| Power Supply | AC 100 to 240V, 50/60 Hz | |
| Method | Direct thermal / Thermal transfer | |
| Resolution | 203/305 dpi ( 8/12 dots/mm) | |
| Maximum Print Width | 160mm | |
| Maximum Print Length | 1490mm | |
| Maximum Print Speed | 305 mm/second (12 ips) | |
| Ribbon Save Function | Yes | No |
| Barcodes | UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Postnet, RM4SCC, KIX-Code, Customer Barcode, GS1 Databar | |
| 2D Codes | Data Matrix, PDF417, MaxiCode, QR Code, Micro PDF417, CP Code, AZTEC Code, GS1 QR Code | |
| Font | Bitmap font, Outline font, Price font, Optional TTF, OTF, Writable characters | |
| RIBBON | ||
| Type of ribbon | Edge head type | Flat head type |
| Maximum Ribbon Width | 170mm | |
| Maximum Ribbon Length | 800 m (Up to 5 inch width) | 600 m |
| MEDIA | ||
| Paper Alignment | Center | |
| Backing Paper Width | 50-165 mm | |
| Label Thickness | 0.13-0.17 mm | |
| Tag Thickness | 0.08-0.25mm | |
| Paper Roll | 200 mm (7.9") | |
| SOFTWARE & CONNECTIVITY | ||
| Printer Driver | Windows 10/8.1 (32/64 bit), Windows Server 2016, Windows Server 2012 R2/Windows Server 2012, SAP | |
| Language Mode | TPCL, ZPL II, BCI (function) | |
| OPTIONS | ||
| Disc cutter, Peel-off module, Fan fold guide, RS232, Centronics, Wireless LAN, EX I/O, RFID Kit* | ||
(*) For T1 model only
