B-EX4T3 |
| CHARACTERISTICS |
| Print head |
Flat head |
| Dimensions |
278 x 460 x 310 mm (W x D x H) |
| Weight |
17 kg |
| Interface |
USB 2.0, Ethernet |
| Optional Interface |
Serial interface, Parallel interface, Expansion I/O interface, RTC & USB Host interface, Wireless LAN interface |
| Network Tool |
SNMP |
| Memory |
64 MB (FROM), 32 MB (SRAM) |
| PRINT |
| Method |
Thermal transfer |
| Print Width |
104 mm (4.09") |
| Max. Print Speed |
152.8 mm/sec (6 ips) |
| Resolution |
600 dpi |
| Font |
Bitmap, Outline, Writable characters, Optional True Type |
| Barcode |
UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Postnet, RM4SCC, KIX-Code, Customer Barcode, GS1 Databar |
| 2D Codes |
Data Matrix, PDF417, MaxiCode, QR Code, Micro PDF417, CP Code, AZTEC Code, GS1 QR Code |
| MEDIA |
| Paper Width |
25 mm - 110 mm |
| Paper Alignment |
Centered |
| Paper Roll |
200 mm (7.9") |
| RIBBON |
| Type of ribbon |
Spool type |
| Maximum Ribbon Width |
115 mm |
| Maximum Ribbon Length |
300 mm |
| SOFTWARE & CONNECTIVITY |
| Printer Driver |
Windows 10/8.1 (32/64 bit),
Windows Server 2016, Windows Server 2012 R2/Windows Server 2012, SAP |
| Language Mode |
TPCL, Basic Command Interpreter
|
