e-STUDIO2018A/2518A/3018A/3518A/4518A/5018A
The e-STUDIO2018A/2518A/3018A/3518A/4518A/5018A comprises an A3/LD-size monochrome MFP series that offers print speeds of 20/25/30/35/45/50ppm. This series of MFPs integrates fast, efficient and security functions in a compact size, which enables you to handle documents in high-volume and high-quality with high-speed anywhere.
Specifications
| Model |
e-STUDIO 2018A |
e-STUDIO 2518A |
e-STUDIO 3018A |
e-STUDIO 3518A |
e-STUDIO 4518A |
e-STUDIO 5018A |
|
|---|---|---|---|---|---|---|---|
| General Feature | |||||||
| Copy / Print Speed (ppm) | 20 | 25 | 30 | 35 | 45 | 50 | |
| Warm-up Time | Approx. 20 sec. | ||||||
| Memory | Std. 2 GB (e-STUDIO 2018A/ 2518A/ 3018A): 4 GB (e-STUDIO 3518A/ 4518A/ 5018A) | ||||||
| Storage | 320GB Self-Encryption HDD | ||||||
| Dimension (W × D × H) | 585 × 586* × 787mm / 23" × 23" * × 31"* | ||||||
| Weight | Approx. 55 kg / 121 lbs | Approx. 58 kg / 128 lbs | |||||
| Input Paper Capacity | Standard | 1,200 sheets | |||||
| Maximum | 3,200 sheets | ||||||
| Available Paper Weight | Single feed: 52 - 256 g/m2 / 14 lb. Bond - 140 lb. Index Multi feed: 60 - 256 g/m2 / 17 lb. Bond - 140 lb. Index |
||||||
| Available Paper size | 100 × 148 to A3 / 100 × 148 to LD | ||||||
| Document feeder | Optional 300-sheet DSDF or 100-sheet RADF | ||||||
| Duplexing | Standard | ||||||
| Finishing Option | Multi-Position stapling finisher, Saddle Stitching Finisher, Inner Finisher, Job Separator | ||||||
| Copier Feature | |||||||
| First Copy Speed | 4.3 sec. | 3.6 sec. | |||||
| Resolution | 2,400 × 600 dpi (with smoothing) | ||||||
| Multiple Copy | Up to 999 | ||||||
| Printer Feature | |||||||
| Resolution | 600 × 600 dpi, 2,400 × 600 dpi (with soothing), 1,200 × 1,200 (PS only), 3,600 × 600 dpi (with soothing/PS only) | ||||||
| PDL | PCL6 Emulation, PS3 Emulation, XPS | ||||||
| Interface | Standard | USB (High speed), 10/100/1000BASE-T | |||||
| Option | Wireless LAN (IEEE802.11 b/g/n), Bluetooth | ||||||
| Scanner Feature | |||||||
| Resolution | 100/150/200/300/400/600dpi | ||||||
| Scan Speed | DSDF | Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi) | |||||
| RADF | Up to 73 spm (300 dpi) | ||||||
| Data format | Standard | TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A | |||||
| Option | DOCX, EXLS, PPTX, Searchable PDF | ||||||
| Scan Protocol | SMB, FTP, IPX/SPX, FTPS, USB, Netware | ||||||
| Scan features | File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan | ||||||
| Internet Fax | ITU-T T.37 (Simple mode) | ||||||
| Fax Feature (option) | |||||||
| Communication mode / Modem Speed | Super G3 / 33.6 kbps- 2.4 kbps | ||||||
| Data Compression | JBIG, MMR, MR, MH | ||||||
| Number of Lines (Std. / Max.) | 1 / 2 | ||||||
| Phonebook | 3,000 stations | ||||||
| Security Feature | |||||||
| Standard | Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP | ||||||
| Optional | Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology | ||||||
* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region.
?
