e-STUDIO6526AC/6527AC/7527AC
The e-STUDIO6526AC/6527AC/7527AC are the next generation of high-end color MFPs boasting a high performance output of 65 and 75 ppm, the fullest range of security features, and cloud ready features. These multifunction printers are the great choice for today’s modern, hybrid work environments.
Specifications
| Model | e-STUDIO6526AC | e-STUDIO6527AC | e-STUDIO7527AC | |
|---|---|---|---|---|
| GeneralFeature | ||||
| Copy / Print Speed (ppm) | Color | 65 | 65 | 75 |
| B & W | 65 | 75 | 85 | |
| Warm-up Time | After power-on | Approx. 20 sec. (68F/ 20C) | ||
| From sleep mode | Less than 15.4 sec. (68F/ 20C) | |||
| From low power mode | Less than 15.4 sec. (68F/ 20C) | |||
| Memory | Std.6GB (Main memory + Page memory) |
|||
| Storage | Std. 128 GB(SSD)(Shared for all imaging functions)/ Opt. 512 GB(SSD) or 320 GB(HDD) | |||
| Dimension(W × D × H) (Height at original glass/Angle of control panel:90 degrees) |
955 × 698 × 1,227 mm / 37.6" × 27.5" × 48.3" | |||
| Weight | Approx. 209 kg / 460.7lbs(Incl. Drum / Developper) | |||
| Input Paper Capacity | Standard | LCF model: 3,520 sheets (20 lb & 80 gsm) 4-drawer model: 2,280 sheets (20 lb & 80 gsm) |
||
| Maximum | LCF model: 8,020 sheets (20 lb & 80 gsm, w/Optional LCF) 4-drawer model: 6,780 sheets (20 lb & 80 gsm, w/Optional LCF) |
|||
| Available Paper Weight (via SFB) |
60 - 300 g/m2 / 16 lb. Bond - 110 lb. Cover | |||
| Available Paper size (via SFB) |
100 x 148 mm to 330 x 483 mm , Banner paper (- 313.4 x 1200 mm) | |||
| Document feeder | Standard 300-sheet DSDF | |||
| Duplexing | Standard | |||
| Finishing Option | Multi-Position stapling finisher, Saddle Stitching Finisher | |||
| Copier Feature | ||||
| First Copy Time | Color | Approx. 5.2 sec. | Approx. 4.5 sec. | Approx. 4.1 sec. |
| B & W | Approx. 6.4 sec. | Approx. 6.4 sec. | Approx. 5.4 sec. | |
| Resolution | Color | 600 dpi x 600 dpi, 5bit | ||
| B & W | 600 dpi x 600 dpi, 1bit *1 600 dpi x 600 dpi, 5bit *2 2400 dpi(Equivalence) x 600 dpi (with smoothing) *3 *1 or *2 or *3 is selected by copy mode automatically.No selectable by user. |
|||
| Gradation | 256 steps | |||
| Multiple Copy | Up to 9999 Copies/ Ten key input | |||
| Printer Feature | ||||
| Resolution | All PDL:600 dpi x 600 dpi, 5bit PS only: 1,200 dpi x 1,200 dpi,2bit(3,600 dpi(Equivalence) x 1,200 dpi) |
|||
| PDL | PCL5e/c, PCL6 (PCL XL), PS3, PDF, XPS, JPEG | |||
| Interface | Standard | 10/100/1000baseT, USB 2.0 High Speed USB | ||
| Option | IEEE802.11b/g/n, Bluetooth | |||
| Scanner Feature | ||||
| Resolution | 100/150/200/300/400/600dpi | |||
| Scan Speed | 120/240 ppm (100,150,200,300 dpi), 80/160 ppm (400 dpi), 70/120 ppm (600 dpi) | |||
| Data format (Color) |
Standard | JPEG, TIFF-Multi/Single Page, PDF-Multi/Single Page, Slim PDF-Multi/Single Page, XPS-Multi/Single Page | ||
| Option | DOCX-Multi/Single Page, XLSX-Multi/Single Page, PPTX-Multi/Single Page | |||
| Scan features | Scan to File, Scan to E-mail, Scan to e-Filing, Scan to WS Scan, Scan to USB, Scan Preview | |||
| Fax Feature (option) | ||||
| Communication mode / Modem Speed | Super G3, G3 / 33.6 kbps- 2.4 kbps (automatic fallback) | |||
| Data Compression | JBIG, MMR, MR, MH | |||
| Number of Lines (Std. / Max.) | 1/2 | |||
| Phonebook | 3,000 stations | |||
| Security Feature | ||||
| Standard | TPM 2.0, Anti-malware, Secure Boot, Self-Encrypting SSD, Private Print, Encrypted/digitally Signed PDF, User Authentication, Role Based Access Control, IP/MAC address filtering, TLS, Data Overwrite, 802.1X, SMBv3, Password policy, SNMPv3, Confidentiality setting, Tampering Prevention of Firmware, Hardcopy Security Printing, SCEP | |||
| Optional | IPsec, FIPS certified Self-Encrypting HDD with Wipe Function, User Authentication(IC Card, Fingerprint, NFC, Multi-factor etc.), Trackable Hardcopy Security Printing | |||
?
*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
