e-STUDIO5516AC/6516AC/7516AC
The e-STUDIO5516AC/6516AC/7516AC are high-end color MFPs that boast a color printing output 55/65/75 ppm. Many amounts of printings and scanning are required for daily work? If yes, here we have some solutions for you. This series of MFPs integrates newly-engineered software, enhanced user interface, and embedded application platform. Such advanced functions are your best business partners in your daily work. ?
Specifications
| Model | e-STUDIO5516AC | e-STUDIO6516AC | e-STUDIO7516AC | |
|---|---|---|---|---|
| General Feature | ||||
| Copy / Print Speed (ppm) | Color | 55 | 65 | 75 |
| B & W | 65 | 75 | 85 | |
| Warm-up Time | Approx. 20 sec. | |||
| Memory | 4 GB | |||
| Storage | 320GB Self-Encryption HDD | |||
| Dimension (W × D × H) | 955 × 698* × 1,227 mm / 37.6" × 27.5"* × 47.7" | |||
| Weight | LCF model: 213 kg / 469 lb, 4-drawer model: 212 kg / 467 lb | |||
| Input Paper Capacity | Standard | LCF model: 3,520 sheets, 4-drawer model: 2,280 sheets | ||
| Maximum | LCF model: 6,020 sheets, 4-drawer model: 4,780 sheets | |||
| Available Paper Weight | 60 - 300 g/m2 / 16 lb. Bond - 110lb. Cover | |||
| Available Paper size | 100 x 148 to 330 x 483mm / 100 x 148 to 13"x19", Banner paper (1,200 mm) | |||
| Document feeder | Standard 300-sheet DSDF | |||
| Finishing Option | Multi-Position stapling finisher,Saddle Stitching Finisher | |||
| Copier Feature | ||||
| First Copy Speed | Color | 6.4 sec. | 6.4 sec. | 5.4 sec. |
| B & W | 5.2 sec. | 4.5 sec. | 4.1 sec. | |
| Resolution | 600 × 600 dpi 2400 dpi × 600 dpi | |||
| Multiple Copy | Up to 9999 | |||
| Printer Feature | ||||
| Resolution | 600dpi x 600dpi 5bit*1 2400dpi (Equivalence) x 600dpi (with smoothing) *2 *1 or *2 is selected by copy mode automatically. No selectable by user. |
|||
| PDL | PCL6 Emulation, PS3 Emulation, XPS | |||
| Interface | Standard | USB (High speed), 10/100/1000BASE-T | ||
| Option | Wireless LAN (IEEE802.11 b/g/n), Bluetooth | |||
| Scanner Feature | ||||
| Resolution | 100/150/200/300/400/600dpi | |||
| Scan Speed | Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi) | |||
| Data format | Standard | TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A | ||
| Option | DOCX, EXLS, PPTX, Searchable PDF | |||
| Scan Protocol | SMB, FTP, IPX/SPX, FTPS, USB, Netware | |||
| Scan features | File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan | |||
| Internet Fax | ITU-T T.37 (Simple mode) | |||
| Fax Feature (option) | ||||
| Communication mode / Modem Speed | Super G3 / 33.6 kbps- 2.4 kbps | |||
| Data Compression | JBIG, MMR, MR, MH | |||
| Number of Lines (Std. / Max.) | 1 / 2 | |||
| Phonebook | 3,000 stations | |||
| Security Feature | ||||
| Standard | Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP | |||
| Optional | Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology | |||
* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region.
?
*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
