e-STUDIO2515AC/3015AC/3515AC/4515AC/5015AC
The e-STUDIO2515AC/3015AC/3515AC/4515AC/5015AC comprises an A3/LD-size color MFP series that offers print speeds of 25/30/35/45/50ppm. With enhanced user interface and mobile printing capabilities, this series of MFPs helps you to print out colorful as well as monochrome documents in high-quality. This series of MFPs allows you to put them anywhere and any size of space with all functions you may need.
Specifications
| Model | e-STUDIO 2515AC |
e-STUDIO 3015AC |
e-STUDIO 3515AC |
e-STUDIO 4515AC |
e-STUDIO 5015AC |
|
|---|---|---|---|---|---|---|
| General Feature | ||||||
| Copy / Print Speed (ppm) | Color | 25 | 30 | 35 | 45 | 50 |
| B & W | 25 | 30 | 35 | 45 | 50 | |
| Warm-up Time | Approx. 20 sec. | |||||
| Memory | 4 GB | |||||
| Storage | 320GB Self-Encryption HDD | |||||
| Dimension (W × D × H) | 585 × 641* × 787 mm / 23" × 25.2"* × 31"* | |||||
| Weight | Less than 78.1 kg / 172.2 lb | |||||
| Input Paper Capacity | Standard | 1,200 sheets | ||||
| Maximum | 3,200 sheets | |||||
| Available Paper Weight | 52 - 280 g/m2 / 14 lb. Bond - 100 lb. Cover | |||||
| Available Paper size | 100 × 148 to 320 x 460mm / 100 × 148 to 12.6" x 18.1", Banner paper (1,200 mm) | |||||
| Document feeder | Optional 300-sheet DSDF or 100-sheet RADF | |||||
| Finishing Option | Multi-Position stapling finisher, Saddle Stitching Finisher, Inner Finisher, Job Separator | |||||
| Copier Feature | ||||||
| First Copy Speed | Color | Less than 7.8 sec. | Less than 5.7 sec. | |||
| B & W | Less than 5.9 sec. | Less than 4.4 sec. | ||||
| Resolution | 600 x 600 dpi, 5bit *1 2,400dpi(Equivalence) x 600dpi (with smoothing) *2 *1 or *2 is selected by copy mode automatically. No selectable by user. |
|||||
| Multiple Copy | Up to 999 | |||||
| Printer Feature | ||||||
| Resolution | 600 x 600 dpi, 5bit | |||||
| PDL | PCL6 Emulation, PS3 Emulation, XPS | |||||
| Interface | Standard | USB (High speed), 10/100/1000BASE-T | ||||
| Option | Wireless LAN (IEEE802.11 b/g/n), Bluetooth | |||||
| Scanner Feature | ||||||
| Resolution | 100/150/200/300/400/600dpi | |||||
| Scan Speed | DSDF | Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi) | ||||
| RADF | Up to 73 spm (300 dpi) | |||||
| Data format | Standard | TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A | ||||
| Option | DOCX, EXLS, PPTX, Searchable PDF | |||||
| Scan Protocol | SMB, FTP, IPX/SPX, FTPS, USB, Netware | |||||
| Scan features | File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan | |||||
| Internet Fax | ITU-T T.37 (Simple mode) | |||||
| Fax Feature (option) | ||||||
| Communication mode / Modem Speed | Super G3 / 33.6kbps - 2.4 kbps | |||||
| Data Compression | JBIG, MMR, MR, MH | |||||
| Number of Lines (Std. / Max.) | 1 / 2 | |||||
| Phonebook | 3,000 stations | |||||
| Security Feature | ||||||
| Standard | Self-encryption HDD with Wipe technology, TLS, Private Print, Encrypted print, Tracking Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC Address filtering, SNMPv3, 802.1X for Wired/Wireless, Fax secure receiving, Fax mis-sending prevention, Security event logging, Password Policy, Integrity Check, HCD-PP | |||||
| Optional | Card authentication, NFC authentication, Data Overwrite, IPsec, Hardcopy Security Printing, FIPS Certified Self-encryption HDD with Wipe technology | |||||
* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region.
?
