e-STUDIO2021AC/2521AC
The e-STUDIO2021AC/2521AC comprises an A3/LD-size color MFP series that offers print speeds of 20/25 ppm. For group projects, for business and for those who need color print function, we are here to assist you. The series incorporates with industry-leading technology and innovations that are designed to help small groups of people stay connect and simple.?
Specifications
| Model | e-STUDIO2021AC | e-STUDIO2521AC | |
|---|---|---|---|
| General Feature | |||
| Copy / Print Speed (ppm) | Color | 20 | 25 |
| B & W | 20 | 25 | |
| Warm-up Time | After power-on | Approx. 21 sec. (68F/ 20C) | |
| From sleep mode | 220 - 240V : Less than 13.1 sec. (68F/ 20C) 120V : Less than 15 sec. (68F/ 20C) |
||
| From low power mode | 220 - 240V : Less than 13.1 sec. (68F/ 20C) 120V : Less than 15 sec. (68F/ 20C) |
||
| Memory | Std. 4GB (Main memory + Page memory) |
||
| Storage | Std. 128 GB (SSD) (Shared for all imaging functions)/ Opt. 512 GB (SSD) or 320 GB (HDD) | ||
| Dimension (W × D × H) (Height at original glass/Angle of control panel:90 degrees) |
585 x 586 x 662 mm / 23.0" × 23.1" × 26.1" | ||
| Weight | Approx. less than 58.9 kg / 129.8 lbs (Incl. Drum) | ||
| Input Paper Capacity | Standard | 350 sheets (250+100) (20 lb & 80 gsm) |
|
| Maximum | 2,900 sheets (20 lb & 80 gsm, w/Optional LCF) | ||
| Available Paper Weight (via SFB) |
60 - 209 g/m2 / 16 lb. Bond - 110 lb. Index | ||
| Available Paper size (via SFB) |
100 × 148 to A3 / 100 x 148 mm to LD | ||
| Document feeder | Optional 100-sheet RADF | ||
| Duplexing | Standard | ||
| Finishing Option | Inner Finisher, Job Separator | ||
| Copier Feature | |||
| First Copy Time | Color | Less than 9.5 sec. | |
| B & W | Less than 7.1 sec. | ||
| Resolution | Color | 600 dpi x 600 dpi, 5bit | |
| B & W | 600 dpi x 600 dpi, 5bit *1 2,400dpi (Equivalence) x 600dpi (with smoothing) *2 *1 or *2 is selected by copy mode automatically. No selectable by user. |
||
| Gradation | 256 steps | ||
| Multiple Copy | Up to 999 Copies/ Ten key input | ||
| Printer Feature | |||
| Resolution | All PDL: 600 dpi x 600 dpi, 5bit PS only: 1,200dpi x 1,200dpi 2bit (3,600dpi(Equivalence) x 1,200dpi) |
||
| PDL | PCL5e/c, PCL6 (PCL XL), PS3, PDF, XPS, JPEG | ||
| Interface | Standard | 10/100/1000baseT, USB 2.0 High Speed USB | |
| Option | IEEE802.11b/g/n, Bluetooth | ||
| Scanner Feature | |||
| Resolution | 100/150/200/300/400/600dpi | ||
| Scan Speed | DSDF | ||
| RADF | 73 ppm (100,150,200,300 dpi), 62 ppm (400 dpi), 50 ppm (600 dpi) | ||
| Data format (Color) |
Standard | JPEG, TIFF-Multi/Single Page, PDF-Multi/Single Page, Slim PDF-Multi/Single Page, XPS-Multi/Single Page | |
| Option | DOCX-Multi/Single Page, XLSX-Multi/Single Page, PPTX-Multi/Single Page | Scan features | Scan to File, Scan to E-mail, Scan to e-Filing, Scan to WS Scan, Scan to USB, Scan Preview |
| Fax Feature (option) | |||
| Communication mode / Modem Speed | Super G3, G3 / 33.6 kbps- 2.4 kbps (automatic fallback) | ||
| Data Compression | JBIG, MMR, MR, MH | ||
| Number of Lines (Std. / Max.) | 1/2 | ||
| Phonebook | 3,000 stations | ||
| Security Feature | |||
| Standard | TPM 2.0, Anti-malware, Secure Boot, Self-Encrypting SSD, Private Print, Encrypted/digitally Signed PDF, User Authentication, Role Based Access Control, IP/MAC address filtering, TLS, Data Overwrite, 802.1X, SMBv3, Password policy, SNMPv3, Confidentiality setting, Tampering Prevention of Firmware, Hardcopy Security Printing, SCEP | ||
| Optional | IPsec, FIPS certified Self-Encrypting HDD with Wipe Function, User Authentication (IC Card, Fingerprint, NFC, Multi-factor etc.), Trackable Hardcopy Security Printing | ||
?
*This service is not available under this name, e-BRIDGE SKY SuiteTM, in the European region.
